AUTOMATIC AC/DC ON-BOARD CHARGER YPOWER 20 Amp
for 12V ALTERNATOR & 36V BATTERY.
Protect your batteries with a custom optimal charge!

The YPOWER 12-36V/20A charger allows for charging a 36V battery bank from the boat's 12V alternator, while benefiting from the advantages of an intelligent charging curve. Thanks to regulation comparable to that of a shore charger, the power delivered is specially suited for Lithium LiFeP04 BSR batteries.

Performance

- 5-stage charging curve for quick and complete charging, continuous power mode available

- Maximum output up to +60°C ambient temperature, with no loss

- Complete charging of batteries guaranteed, even for intensive use, in warm and confined environments.

- Allows up to 3 independent battery banks, with no current limitation

- Compatible with all types of batteries, including flooded and sealed lead, Calcium lead, AGM, gel, Lithium Ion, etc…

- Extends battery lifespan

- No fan (fanless technology)

- Thermostatically controlled electro-fan on the 24V/30A model

Features

- BUS-CAN interface for data transfer (optional)

- Up to 4 chargers can be connected in parallel to increase the charging current.

- External temperature probe for monitoring the battery compartment temperature (optional)

- Remote 2.4'' colour touch display (optional)

- Charger fault relay for low battery voltage (optional)

Ergonomics

- Quick and easy installation: simple wall mounting & Plug & Play connectors

- Optimal accessibility: easy to position even in tight spaces

- Comfortable readability: LED indicators and dedicated icons on the front

International compatibility

- Automatic detection of the input network, 90-265VAC/47-65Hz

- Use worldwide, including on generators whatever the available voltage

- Memory function in case of network instability: charging resumes where it left off

- Enhanced protection with replaceable fuses and surge protectors, tropicalised and de-bugged electronic board
